product presentation
OSEN-WATER swimming pool water quality monitoring system, is a set of online automatic monitoring instruments as the core, using modern sensor technology, automatic measurement technology, and other related analysis software and communication network composed of a comprehensive online automatic monitoring system. The online monitoring system combines the analysis instruments of multiple monitoring indicators together. From pumping sampling, analysis to data sorting, real-time online automatic monitoring is realized to meet the requirements of reliable and stable operation and less maintenance.
This system can be used to determine the residual chlorine, PH value, turbidity, ORP, water temperature and other water quality parameters, users can select according to their own needs, convenient integration. The online detection system mainly includes a large-screen display system, a terminal display and a controller, various types of detection sensors, a remote mobile terminal, and a cloud data platform. It mainly detects the indicators in the swimming pool water, and the need to jointly control the drug pump equipment. When the water quality index is abnormal, the drug pump can be automatically controlled to adjust the water quality, and push the information background to remind the staff.
Product Features
(1) Residual chlorine without consumables, constant speed motor grinding and cleaning, maintenance free
(2) Low turbidity automatic hanging film optional configuration, maintenance free
(3) Fermentation drift free technology pH design, long maintenance cycle
(4) The sensor adopts a consumable free design concept, with low usage cost and no secondary pollution
(5) Ultra low flow design, drainage capacity<5L/h, saving water resources
(6) Flow pool water cut-off protection function, electrode does not need to be disassembled
(7) Sensor pre diagnostic system, capable of providing maintenance and consumable replacement prompts
(8) 6-way relay output, can be used for automatic sensor cleaning, box sampling, drainage, and pollution control
(9) Full range measurement factor compatibility, multi parameter function (≤ 6 parameters), optional matching according to needs
(10) Color TFT large screen, Chinese display interface, clear and intelligent
(11) USB interface data recording and export function, easy to use
(12) Customized enclosure with reserved inlet and outlet ports for quick installation
(13) Multiple installation methods such as scaffolding and wall hanging, to match the on-site situation
Product application
(1) 24-hour uninterrupted real-time monitoring and display on the screen next to the swimming pool;
(2) Wireless remote monitoring - managers can monitor the pool environment without physically visiting the site;
(3) Automatic alarm - can be alerted through SMS, APP, and other means;
(4) Management, analysis, and statistics of monitoring data, and regular generation of monitoring reports;
(5) Internet access ? users can browse real-time monitoring data and monitoring reports online;
(6) Remote control ? users can control the terminal equipment through the Internet, mobile phone SMS, etc., for example, they can control the oxygen delivery equipment or water temperature regulating device according to the set time, conditions or user instructions.
Product Parameter
|
order number
|
name
|
specifications
|
|
1
|
Host acquisition system
|
l Data storage: the original monitoring data can be stored for one year;
l Data transmission: support real-time and timing data upload, remote can be set;
l Interface: with RS485 / RS232 / RJ 45 network port, SD card interface;
l Data communication: support Ethernet, optical fiber, 4G, 5G and other communication;
l Data download: automatic download of data to the remote computer, support for manual
l Have to their own routine fault automatic diagnosis, automatic alarm, and display and save the corresponding record function;
l Automatic data collection and control software supports all kinds of environmental index parameter collection function, providing real-time data to LED display function;
|
|
2
|
digital PH
sensor
|
l Range: 0-14ph
l Pressure withstand range: 0-1.5bar
l Operating temperature: -5-85℃
|
|
3
|
Digital residual chlorine
sensor
|
l Measurement method: gold and silver variable voltage method
l Range: 0-3 mg/L; 0-12 mg/L
l Resolution: 0.01 mg/L
l Measurement accuracy:±5% or±0.02 mg/L to take the maximum value
l Temperature compensation: built-in temperature sensor, automatic temperature supplement
l Output signal: RS485
|
|
4
|
Digital turbidity
sensor
|
l Measurement method: 90°infrared scattered light method
l Range: 0-20 NTU
l Resolution: 0.001 NTU
l Measurement accuracy:±5% or±0.01 NTU with larger value
l Temperature compensation: automatic cleaning.1-200 hours can be set arbitrarily
l Output signal: RS485
|
|
5
|
Water temperature sensor
|
Measuring range: 0~50℃, precision:±0.5℃, resolution: 0.1℃
|
|
6
|
display mode
|
7-inch touch HD display screen, LED display screen, LCD screen, PC terminal platform, mobile terminal APP / public account, etc
|
|
7
|
Data reported
|
The reporting time interval can be set and can be uploaded to the cloud through the 4G wireless transmission module
|
|
8
|
presentation of information
|
RS485,4G wireless transmission (support docking to multiple third-party platforms)
|
|
9
|
data storage
|
Built-in large-capacity SD card data local storage, can be exported to the local
|
|
10
|
working voltage
|
mains AC220V and solar power supply system (optional)
|
|
11
|
Water mining system
|
Built-in automatic water pump and measuring tank to realize automatic drainage system and circulation system
|
|
12
|
Cloud platform monitoring
|
Cloud platform remote real-time data view, historical data download, threshold setting, excessive alarm push, data analysis and other functions.
|
Smart swimming pool water quality monitoring and control platform
Wisdom pool water quality monitoring control platform based on "water environment monitoring + Internet of things" and "big data" advanced concept, connect the local health supervision and management system platform, the swimming pool water quality monitoring equipment online water quality data upload monitoring platform, through the management end, supervision and law enforcement, the social public end three ports, realize the enterprise autonomy, government supervision, the public participation in the wisdom of the regulatory mode. People can online channels to view the area all swimming basic information, health credibility level, health supervision and inspection information, real-time grasp the pilot swimming places health management status and water quality information, can also complain to the area of swimming health problems, realize the benign interaction of social public participation supervision, let people trust consumption.
